FrameScale 3 Carbon / IMP Technology / HMFBB92 / SW DM dropouts for Boost 12x148mmSDS2 advanced Shock & Standing Damping SystemICCR Cable routing
ForkFOX 32 Float Rhythm Grip 33-Modes / 15x110mm QR axle / 44mm offset / tapered steererReb. Adj. / Lockout / 100mm travel
Remote SystemSCOTT RideLoc Technology / below bar remote3 modes / integ. Grip clamp
Rear DerailleurShimano XT RD-M8100 SGSShadow Plus / 12 Speed
ShiftersShimano Deore SL-M6100-IR / Rapidfire PlusIspec EV clamp
CranksetShimano SLX FC-M7100-1 / Hollowtech 232T
BB-SetShimano BB-MT500 / shell 41x92mm
ChainShimano CN-M6100
CassetteShimano Deore CS-M6100-12 / 10-51 T
BrakesShimano M4100 Disc
RotorShimano SM-RT54 CL / 180/F and 160/R
HandlebarSyncros Fraser 2.0 / Alloy 6061T shape Flat / 9° / 740mmSyncros Pro lock-on grips
H'stemSyncros FL2.06° / integrated Spacer & Top Cap6061 Alloy / 31.8mm / 1 1/8"
SeatpostSyncros Duncan 2.0 / 10mm offset31.6x400mm
SeatSyncros Belcarra Regular 2.0CRMO rails
HeadsetSyncros Pro Drop in / Tapered 1.5"-1 1/8"Bearing diameter size 42mm and 52mm
Hub (Front)Formula CL-811 / 15x110mm
Hub (Rear)Formula CL-148M / Boost 12x148mm / Micro Spline
SpokesStainless Black 15G / 1.8mm
RimsSyncros X-25 / 32H / 25mmTubeless ready
Front TireSchwalbe Racing Ray 29x2.25" / Performance Folding / Addix / TLE Tubeless ready
Rear TireSchwalbe Racing Ralph 29x2.25" / Performance Folding / Addix / TLE Tubeless ready
Approx weight in KG11.50
Approx weight in LBS25.35
Max. System Weight128 kgThe overall weight includes the bikethe riderthe equipmentand possible additional luggage.
